A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 521 / 812
5.3.4.78. DEFE_CH0_VERTCOEF_REGN (N=0 :31)
Offset: 0x500+N*4
Register Name: DEFE_CH0_VERTCOEF_REGN
Bit
Read/
Write
Default/
Hex
Description
31:24
R/W
0x0
TAP3
Vertical tap3 coefficient
The value equals to coefficient*2
6
23:16
R/W
0x0
TAP2
Vertical tap2 coefficient
The value equals to coefficient*2
6
15:8
R/W
0x0
TAP1
Vertical tap1 coefficient
The value equals to coefficient*2
6
7:0
R/W
0x0
TAP0
Vertical tap0 coefficient
The value equals to coefficient*2
6
5.3.4.79. DEFE_CH1_HORZCOEF0_REGN (N=0 :31)
Offset: 0x600+N*4
Register Name: DEFE_CH1_HORZCOEF0_REGN
Bit
Read/
Write
Default/
Hex
Description
31:24
R/W
0x0
TAP3
Horizontal tap3 coefficient
The value equals to coefficient*2
6
23:16
R/W
0x0
TAP2
Horizontal tap2 coefficient
The value equals to coefficient*2
6
15:8
R/W
0x0
TAP1
Horizontal tap1 coefficient
The value equals to coefficient*2
6
7:0
R/W
0x0
TAP0
Horizontal tap0 coefficient
The value equals to coefficient*2
6
