Allwinner A20 - Page 522

A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 522 / 812
5.3.4.80. DEFE_CH1_HORZCOEF1_REGN (N=0 :31)
Offset: 0x680+N*4
Register Name: DEFE_CH1_HORZCOEF1_REGN
Bit
Read/
Write
Default/
Hex
Description
31:24
R/W
0x0
TAP7
Horizontal tap7 coefficient
The value equals to coefficient*2
6
23:16
R/W
0x0
TAP6
Horizontal tap6 coefficient
The value equals to coefficient*2
6
15:8
R/W
0x0
TAP5
Horizontal tap5 coefficient
The value equals to coefficient*2
6
7:0
R/W
0x0
TAP4
Horizontal tap4 coefficient
The value equals to coefficient*2
6
5.3.4.81. DEFE_CH1_VERTCOEF_REGN (N=0 :31)
Offset: 0x700+N*4
Register Name: DEFE_CH1_VERTCOEF_REGN
Bit
Read/
Write
Default/
Hex
Description
31:24
R/W
0x0
TAP3
Vertical tap3 coefficient
The value equals to coefficient*2
6
23:16
R/W
0x0
TAP2
Vertical tap2 coefficient
The value equals to coefficient*2
6
15:8
R/W
0x0
TAP1
Vertical tap1 coefficient
The value equals to coefficient*2
6
7:0
R/W
0x0
TAP0
Vertical tap0 coefficient
