Allwinner A20 - Page 800

A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 800 / 812
6.16.5.20. CAN TX/RX MESSAGE BUFFER 9 REGISTER (TRANSFER MODE)
Offset: 0x64
Register Name:
CAN_TXBUF9
Default Value: 0x0000_0000
Bit
Read/Write
Default
Description
31:8
/
/
/
7:0
R/W
0
SDATA7_EDATA5
SFF-TX data byte 7 / EFF- TX data byte 5
6.16.5.21. CAN TX/RX MESSAGE BUFFER 10 REGISTER (TRANSFER MODE)
Offset: 0x68
Register Name:
CAN_TXBUF10
Default Value: 0x0000_0000
Bit
Read/Write
Default
Description
31:8
/
/
/
7:0
R/W
0
SDATA8_EDATA6
SFF-TX data byte 8 / EFF- TX data byte 6
6.16.5.22. CAN TX/RX MESSAGE BUFFER 11 REGISTER (TRANSFER MODE)
Offset: 0x6C
Register Name:
CAN_TXBUF11
Default Value: 0x0000_0000
Bit
Read/Write
Default
Description
31:8
/
/
/
7:0
R/W
0
EDATA7
EFF- TX data byte 7
6.16.5.23. CAN TX/RX MESSAGE BUFFER 12 REGISTER (TRANSFER MODE)
Offset: 0x70
Register Name:
CAN_TXBUF12
Default Value: 0x0000_0000
Bit
Read/Write
Default
Description
31:8
/
/
/
7:0
R/W
0
EDATA8
EFF- TX data byte 8
