Brake System
Argo Service Manual
Ontario Drive & Gear Limited www.odg.com
PH.(519)- 662-2840 FAX (519)- 662-2421
BR-9
Hydraulic Brake Calipers
Maintenance Schedule - Inspect every 50 hrs of vehicle operation
The brakes must be inspected regularly by a qualified mechanic. Damaged or
leaking calipers can seriously impair the ARGO steering/ braking capability. Severe
personal injury or property damage could result from a damaged or poorly adjusted
brake system.
Inspect the calipers for the conditions listed in the chart below and then perform the
recommended servicing procedures.
Condition Corrective Action Servicing Procedure Page
Cracked or Broken Replace Immediately Hydraulic Brake Caliper Re- BR-10
Calipers moval
Broken or Missing Brake Caliper Service BR-11
CotterPins and Repair
Hydraulic Caliper Installation BR-14
Hydraulic Fluid Inspect Caliper Hydraulic Brake Caliper Re- BR-10
Leakage Casting and “O” Ring moval
Inspect Hoses and Brake Caliper Service and
Connections Repair BR-11
Inspecting the Hydraulic
Brake line BR-26
Hydraulic Caliper Installation BR-14
