Clutch System Argo Service Manual
Ontario Drive & Gear Limited www.odg.com
PH.(519)- 662-2840 FAX (519)- 662-2421
CS-18
Maintenance Schedule-Inspect every 50 hours of vehicle operation
Inspect the nylon sliders every 50 hours. The nylon sliders are mounted in the driven
clutch moveable pulley. When the clutch shifts, the cam moves on the nylon sliders.
Replace the nylon sliders before there is aluminum to aluminum contact between the cam
and the moveable pulley. Driven clutch disassembly is required to replace the nylon
sliders properly.
Lubricate the driven clutch every 50 hours with a silicone based lubricant such as WD-40.
Spray the lubricant into the clutch unit, directing the spray onto the spring, bushing and
the sliding areas of the cam pulley and the fixed cam where the cam shoes make contact.
Do not attempt to lubricate the driven clutch while the engine is running.
Do NOT spray lubricant onto the drive belt, brake disc or clutch faces. Allow the
lubricant to dry before using the vehicle. If the lubricant is not dry, use of the vehicle will
attract dirt and cause damage to the clutch components.
A complete service of the clutch units is required after every 250 hours of operation. To
perform this procedure, the clutches must be disassembled. Special tools are required to
disassemble the clutch units. Perform the servicing procedures, Driven or Driver Clutch
Removal & Disassembly in this section of the service guide.
Driven Clutch Lubrication
2. Perform the servicing procedure, Removing the Firewall, in section VB of this
service guide.
3. Inspect the clutch. Perform the servicing procedure, Driven Clutch Removal/Dis-
assembly, if:
Driven Clutch Inspection
the clutch plates have tracking grooves caused by drive belt action
the clutch plates are cracked or bent
the nylon cam slider shoes are missing, melted, or worn through
the spring is broken or has come loose from the cam or moveable face
1. Remove the engine access cover.
