Argo Service Manual General Information
Ontario Drive & Gear Limited www.odg.com
PH.(519)- 662-2840 FAX (519)- 662-2421
GI-13
Transmission
Side Cover Bolts............................................................. 216 IN. LBS. 24.3Nm
Differential Bolts.............................................................35 FT. LBS. 47.5Nm
Shifter Plate Bolts (Avenger)..........................................75 IN. LBS 8.5Nm
Intake & Exhaust
Kawasaki Exhaust Manifold to Engine...........................204 IN. LBS. 23.2Nm
Kawasaki Muffler to Engine...........................................204 IN. LBS 23.2Nm
Briggs Muffler to Engine................................................204 IN. LBS 23.2Nm
Briggs Exhaust Man. to Engine...................................... 204 IN. LBS. 23.2Nm
Kohler Exhaust Man. to Engine (Avenger).....................204 IN. LBS 23.2Nm
Clutch System
Driver Clutch Nut on Clutch.......................... ................100 FT. LBS. 135.6Nm
Driver Clutch Bolt to Briggs Engine.............................. 50 FT. LBS. 67.8Nm
Driver Clutch Bolt to Kohler Engine (Avenger)..............40 FT. LBS 54.3Nm
Driver Clutch Bolt to Kaw. Engine ............... ................50 FT. LBS. 67.8Nm
Driven Clutch Bolt to Input Shaft...................................15 FT. LBS. 20.3Nm
Spring Cover Cap Screws...............................................85in. lbs. 9.6Nm
ARGO Torque Specifications
Powerpak Assembly
Engine to Powerpak Frame (Kaw)..................................30 FT. LBS. 40.7Nm
Engine to Powerpak Frame (Briggs................................24 FT. LBS. 32.6Nm
Engine to Powerpak Frame (Kohler)...............................35 FT. LBS 47.5Nm
Transmission to Powerpak Frame...................................75 FT. LBS. 101.7Nm
Brake Cooling Air Duct to Frame.................. ................35 in.lbs. 4.0Nm
Master Cylinder Mounting Bolts....................................96 IN. LBS. 10.7Nm
Belt Guard to Transmission........................... ................30 FT. LBS. 40.7Nm
Brake Bracket Mounting Bolts....................................... 240 IN. LBS. 27.1Nm
Power Pack Bolts to Main Vehicle Frame.......................80 FT. LBS. 108.2Nm
Brake System - Hydraulic
Brake Caliper to Transmission........................................45 FT. LBS. 61.0Nm
Brake Caliper Assembly Bolts (M10) (Gremica)........... 33 FT. LBS. 44.8Nm
Brake Caliper Assembly Bolts (M8) (Gremica)............. 17 FT. LBS. 23.2Nm
Hydraulic Hose Bolts......................................................180 IN. LBS. 20.3Nm
Avenger Brake Caliper Assembly Bolts .........................218 IN. LBS 24.6Nm
