Argo Service Manual Fuel System
Ontario Drive & Gear Limited www.odg.com
PH.(519)- 662-2840 FAX (519)- 662-2421
FS-7
• cracks, breaks or punctures in all fuel lines and hoses.
• cracked fuel filter casing
If any of these conditions exist, replace the affected component parts immediately.
Removing the Fuel Tank (6x6 Vanguards prior to S7304)
1. Drain the fuel tank.
2. Plug the filler pipe with a rag to prevent any foreign material from entering the tank.
7. Remove the fasteners securing the bench seat to the top of the fuel tank.
9. Disconnect the fuel line from the pickup tube.
13. Undo the gear clamp at the tank and pull the filler hose assembly free of the tank.
The vent tubing may remain attached to the metal neck assembly.
3. Remove the backrest. Locate and pry loose the 3 grey plugs in the upper
body behind the backrest.
4. Using a socket and extension, remove the 3 bolts and washers holding the backrest to
the upper body.
5. Lift the backrest out of the vehicle.
6. Remove the front floor pan.
8. Remove the seat cushion.
10. Slide the fuel tank and cage 2 or 3 inches toward the firewall.
11. Rotate the fuel tank 90 degrees.
12. Lift the fuel tank out of the seating compartment, sliding the fuel neck assembly out
of the upper body.
The vent tubing for the fuel system is attached to the metal filler neck section of the
filler neck assembly. Caution should be observed as not to damage the outlet nipple
welded to the metal neck assembly. Any bending or kinking of this small tube will
prevent the tank from venting causing serious performance issues later on.
14. Remove the tank & seat cage from the vehicle.
