Argo S - Disassemble the Spline Shaft Drive Gear Assembly

Ontario Drive & Gear Limited www.odg.com
PH.(519)- 662-2840 FAX (519)- 662-2421
TR-6A
Transmission Argo Service Manual
TR-21
TR-22
TR-23
22. Remove the last ball bearing from the input shaft at the arbor press.
Photo TR-24
TR-24
Disassemble the Spline Shaft Drive Gear Assembly
23. Remove the bearing and high gear from
the spline shaft at the arbor press.
Photo TR-25
TR-25
24. Remove low gear, reverse gear, drive
gear and bearing from the spline shaft
using the the arbor press.
Photo TR-26
