Ontario Drive & Gear Limited www.odg.com
PH.(519)- 662-2840 FAX (519)- 662-2421
TR-5A
Argo Service Manual Transmission
TR-15 TR-16
TR-17 TR-18
17. Using an arbor press, remove the smaller ball bearing from the end of the
input shaft. Photo TR-19
18. Remove the retaining ring at the reverse gear. Photo TR-20
TR-19 TR-20
19. Remove the reverse and low gear from the input shaft at the arbor press.
Photo TR-21
20. Slip the dog clutch from the input shaft and remove the retaining ring & Thrust
Washer found above the High Gear. Photo TR-22
21. Slip the high gear from the input shaft, PhotoTR-22 and remove the thrust washer
and Retaining Ring found below it. Photo TR-23
To Next Page
