Ontario Drive & Gear Limited www.odg.com
PH.(519)- 662-2840 FAX (519)- 662-2421
Argo Service Manual Transmission
TR-27
TR-69 TR-70
Assembling the Differential
1. Secure the Aluminum Cage to the base of the arbor press using a spacer and nut.
Photo TR-69
2. Install (6) Oilite Bushings into the Aluminum Cage. Photo TR70
3. Repeat the process installing these bushings into the appropriate Gear Plate. Photo
TR-71
The (3) Gear Plates used are:
M-Gear Plate
H-Gear Plate
G-Gear Plate
TR-71 TR-72
Transmission Assembly
4. Blow all foreign debris from the Cage and Gear Plate. Photo TR-72
To Next Page
