Argo Service Manual Transmission
TR-25
Transmission Component Changes Since 1992
Argo Transmission Assembly
This chart indicates changes to some of the transmission components since 1992. Most,
if not all are fully exchangeable if your original part is no longer available. When or-
dering replacement parts, begin by referring to the correct parts manual for your year and
model of ARGO. If the component is no longer listed in your Spare Parts Price List
(Distributors & Dealers Only), check the Superceded Section for the correct part(s) that
replace(s) the original.
Shaft, Splined &
Gear, Helical
Affects earlier Vanguards
Transmission Component Description of Change
Apr 29/1992 Keys are eliminated on the spline shaft.
Helical gears and splined shafts are coupled by an
extended 6PL.-spline. Fully Exchangeable.
From Serial Numbers:
CB16459 TB Oct. 27/99
RB16446TB Oct. 26/99
BF11143 TB Oct. 21/99
S11188 TB Nov. 17/99
SN11196 TB Nov. 17/99
Jul 07/1999 The output shaft and brake discs are
now splined eliminating the need for the 110-14
keys. Older stock is still available.
Fully Exchangeable but both shaft and disc need to
be replaced together. Refer to the appropriate illus-
trated parts manual for the new part numbers.
34-81 Output Shaft
610-24H Brake Disc
810-01 Brake Disc
Jun 12/2000 Reason for Change -To limit the possi-
bility of the transmission coming out of gear in
certain situations.
SN11905 TB Oct. 4/00
S11906 TB Oct. 4/00
BF11917 TB Oct. 10/00
CB17471 YB Oct. 12/00
RB17525 Oct. 24/00
Shift Gate (New)
From Serial Numbers:
