Argo Service Manual Clutch System
Ontario Drive & Gear Limited www.odg.com
PH.(519)- 662-2840 FAX (519)- 662-2421
CS-17
CS-43
CS-42
Installing the Driver Clutch
1. Apply anti-seize compound to the engine PTO shaft.
2. Install the key to the keyway of the PTO shaft.
3. Install the mounting hardware into the driver clutch before attempting to slip the
clutch on to the PTO of the engine. The hardware cannot be installed after the clutch
has been slipped into place.
IMPORTANT
The driver clutch should slip on and up to the shoulder by hand. There should not
be any reason to use a mallet to install the clutch.
4. Align the keyway of the driven clutch with that of the previously installed key on
the PTO, and slip the clutch on and up to the machined shoulder.
Refer to page CS-6 in reference to the hardware used for the particular model and year of
vehicle being serviced.
5. Torque hardware to specifications.
6. Perform the servicing procedure, Installing the Drive Belt.
7. Perform the servicing procedure, Installing the Firewall in section VB.
In some cases the lower body may have to be pushed out a little to allow the clutch room
to slip on to the PTO shaft.
