Argo S - Clutch System

Argo Service Manual Clutch System
Ontario Drive & Gear Limited www.odg.com
PH.(519)- 662-2840 FAX (519)- 662-2421
CS-1
Table of Contents
SECTION CS
Clutch System
General Instructions............................................................................. CS-2
Maintenance Information.....................................................................CS-3
Drive Belt Inspection.............................................................................CS-3
Removing the Drive Belt.......................................................................CS-4
Installing the Drive Belt.........................................................................CS-5
Driver Clutch Inspection......................................................................CS-5
Driver Clutch Removal.........................................................................CS-5
Disassembling the Driver Clutch (Threaded Bushing Spring Cap). CS-7
Disassembling the Driver Clutch (Cap Screw Spring Cap)...............CS-9
Disassembling the Driver Clutch (P/N 127-135) Supplement Pages.CS-9A
Assembling the Driver Clutch (P/N 127-135)Supplement Pages...... CS-9A
Assembling the Driver Clutch (Threaded Bushing Spring Cap)......CS-11
Assembling the Driver Clutch (Cap Screw Spring Cap)...................CS-14
Installing the Driver Clutch ............................................................... CS-17
Driven Clutch Lubrication...................................................................CS-18
Driven Clutch Inspection......................................................................CS-18
Driven Clutch Removal........................................................................ CS-20
Driven Clutch Disassembly...................................................................CS-20
Driven Clutch Reassembly....................................................................CS-23
Testing the Spring Load of the Driven Clutch....................................CS-25
Installing the Driven Clutch ................................................................CS-25
