Wheels, Axles & Chains Argo Service Manual
Ontario Drive & Gear Limited www.odg.com
PH.(519)- 662-2840 FAX (519)- 662-2421
WA-10
4. Remove the vice-grips, securing the cam assembly in its lowest position.
Drive Chain Lubrication
Maintenance Information - Lubricate every 10 hrs. of vehicle operation.
*Lubricate more frequently if the vehicle is being operated under wet or dusty conditions
2. Remove both front and rear floor pans.
3. Lubricate the chains with Aerosol Chain Lube (ARGO part No. 125-86).
After every 100 hrs. of operation, remove all the drive chains from the vehicle and clean
them thoroughly in a suitable solvent, e.g clean varsol bath.
Never use gasoline as a cleaning solvent. Gasoline is extremely flammable and can
explode if ignited, causing serious personal injury.
Drive Chain Cleaning
Allow the chains to dry thoroughly, re-lubricate generously with ARGO Chain
Lube and reinstall.
Idler Chain Lubrication
Lubricate the idler chains after 10 hrs. of operation, and more frequently if the vehicle is
operated in dirty or wet conditions. Use an aerosol type of motorcycle chain lube such as
the type available through Ontario Drive & Gear. Part No. 125-86
When applying the chain lube, protect the brake disc with a rag or simple cardboard
shield. Do not allow chain lube to come into contact with the brake discs or brake pads.
Roll the vehicle so that all the idler chain is accessible for lubrication.
1. Perform the servicing procedure, Removing the Firewall, in section VB
of this service manual.
5. With the wheels raised up off the ground, reach under the slider block assembly and
pull it up into the highest position that the chain will allow. See DIAGRAM WA-15
on page WA-11
6. Replace the firewall and floor pans.
