Argo S - Assembling the Chain Tensioner System; If the Chain Tensioner System Is Being Installed on an Outside Chain; If the Nylon Slider Block Needs Replacing

Wheels, Axles & Chains Argo Service Manual
Ontario Drive & Gear Limited www.odg.com
PH.(519)- 662-2840 FAX (519)- 662-2421
WA-16
6. Slip the one torsion spring off the cam, and remove the second torsion spring from
the frame assembly by removing the cotter pin that secures it.
Photo WA-27
WA-27
If the nylon slider block needs replacing:
WA-28 WA-29
4. Insert the end of the pivot pin with the cotter pin hole, through the inner
channel of the vehicle frame. Photo WA-30
Assembling the Chain Tensioner System


 On 8x8 models manufactured prior to serial numbers CB16049 & RB16104, or
6x6 models prior to serial numbers SN10191 & S10178:
If the chain tensioner system is being installed on an outside chain:
3. Press firmly on to the tensioner arm. Use light strokes of a rubber mallet if neces-
sary. Photo WA-29
2. Position one end of the new slider block on to the tensioner arm.
1. Place the tensioner arm on to a solid surface, such as the top of a vise.
Photo WA-028
WA-26
