Engine System Argo Service Manual
Ontario Drive & Gear Limited www.odg.com
PH. (519)- 662-2840 FAX (519)- 662-2421
Installing The Engine (Kohler Avenger Model)
1. Install the (5) shims to the PTO of the engine. Photo 1
2. Apply anti-seize compound to the PTO. Photo 2
3. Install the key to the keyway of the PTO. Photo 3
4. Slide the driver clutch on and up to the shoulder of the PTO. Photo 4
1 2
3 4
5. Secure the driver with the hex head fastener. Apply blue LOCTITE and Torque to
specifications. Photo 5
For part number and descriptions of all components and hardware, always refer to
your illustrated Argo parts manual.
IMPORTANT
6. Install the muffler assembly to the engine manifold. Photo 6
IMPORTANT
Always use new manifold gaskets
EN-25A
