Ontario Drive & Gear Limited www.odg.com
PH.(519)- 662-2840 FAX (519)- 662-2421
Transmission Argo Service Manual
TR-42
43. Use compressed air to blow any foreign
debris from the Housing before attempt-
ing to install the sub-assembled com-
ponents. Photo TR-149
Install the Differential Assembly.
44. Place the Differential into the Housing, slipping the Output Shaft into the Output
Shaft Bearing. Press at the arbor until the shoulder of the Aluminum Cage is seated
to the Bearing. Photo TR-150, 151 & 152
Install the Shifter Assembly
45. Take the pre-assembled Shifter Assembly and place the Double Gear into the high
gear gate on the spline (Lowest Position). Photo TR-153
TR-149
TR-150 TR-151
