1. Locate the tailpipe assembly and detach the connecting springs between the tailpipe
assembly and muffler. Photo 1 & 2 Pull the assembly out through the hood area.
1 2
2. Remove the heat deflector shield covering the muffler. Photo 3
Disconnect All Wiring
3. Disconnect the fuel line from the fuel filter at the carburetor. Photo 4
3 4
4. Disconnect the ground cable at the engine. Photo 5 & 6
Removing the Engine (Kohler Aegis N.A)
5
6
EN-20A
