Brake System Argo Service Manual
BR-46
Ontario Drive & Gear Limited www.odg.com
PH.(519)- 662-2840 FAX (519)- 662-2421
27. Mount the other side of the brake cooling duct using a bolt, lock washer and flat
washer. Attach this end using the same bolt that secures the steering bracket to the
rear threaded transmission boss. Photo BR-94
Before securing the brake cooling duct, be sure that the engine wire harness plug is
accessible above the ducting. (Conquest Models Only) Photo BR-95
IMPORTANT
BR-93 BR-94
BR-95
Brake Cooling System
All 6x6 Bigfoot and Eight wheel vehicles with hydraulic brakes have a 12 volt fan forcing
cool air from outside the engine compartment onto the brake components to protect the
system from overheating. Overheating can damage the hydraulic brake components.
Make sure the brake cooling fan is operating when the vehicle is being driven. The fan
operates when the ignition switch is in the “run” position. Keep the brake cooling system
in good working order by:
• cleaning debris from the air intake screen and ducts.
• keeping electrical connections tight and components securely mounted.
