Ontario Drive & Gear Limited www.odg.com
PH.(519)- 662-2840 FAX (519)- 662-2421
Argo Service Manual Transmission
TR-41
TR-147 TR-148
39. Insert the Dowel Pin into the boss of the transmission housing and using a soft face
mallet, tap it flush to the sealing edge of the housing. Photo TR-145
40. Install the Retaining Ring to the bottom of
the Dowel Pin. Photo TR-146
TR-145
TR-146
42. Place the Housing into a fixture for final assembly. Photo TR-148
41. Attach the Shifter Lever assembly temporarily to the Holder. Photo TR-147
