Ontario Drive & Gear Limited www.odg.com
PH.(519)- 662-2840 FAX (519)- 662-2421
Transmission Argo Service Manual
TR-28
5. Install a Bearing into both Cage and Gear plate. Photo TR-73 & 74
6. Wipe the Output Shaft free of debris with a lint free rag. Install this Output
Shaft into the Aluminum Cage. Photo TR-75 & 76
TR-73
TR-74
TR-75 TR-76
Use a spacing tool to secure the previously
installed Bearing inside the Aluminum Cage
while the Output Shaft is pressed into place.
Photo TR-77
TR-77
See Transmission Component Changes chart on page TR-25 regarding output shafts.
