Brake System
Argo Service Manual
Ontario Drive & Gear Limited www.odg.com
PH.(519)- 662-2840 FAX (519)- 662-2421
BR-13
When reassembling the caliper, work with clean hands, tools, and parts. Perform the
reassembly on a clean, neat surface. Dirt or contaminants on component parts will
cause a reduction in brake efficiency and may damage the brake components.
Do not scratch or tear the seals during installation. Any damaged seal must be
replaced immediately.
5. Insert the pistons so that the cavity side is facing up.
6. Place the one half caliper into the aluminum jawed vise being careful not to damage
it by overtightening it. Locate the oil journal which requires the small “O” ring.
Place the “O” ring over the hole making sure that the flat edge of the ring is facing
down. Photo BR-15
7. Place the other half caliper to the one secured in the vise making sure that the oil
journal of the top half is aligned with the previously installed “O” ring in the lower
half. Photo BR-16
3. Place the caliper castings on a clean workbench so that the interior is fac-
ing up. Photo BR-13
4. Insert the rubber seals into each half of the caliper casting. Photo BR-14
BR-13 BR-14
