There are (3) small lockwashers on these (3) fasteners. Ensure that they are still
in place before re-installing and torquing the spring cap back down.
4. Re-install the nylon block and weight assemblies into the sliding flange. Orient the
block with the rounded side up. Photo 9
5. Re-install the cap and secure with flat washer and nut. Torque to 100 FT. LBS.
135.6Nm
9
10
NO NO
NO NO
NO
TETE
TETE
TE
To properly torque, re-install the driver to the engine PTO and lock flywheel while using the torque
wrench to achieve proper torque.
