Ontario Drive & Gear Limited www.odg.com
PH.(519)- 662-2840 FAX (519)- 662-2421
Transmission Argo Service Manual
TR-22
50. Remove all (12) Oilite Bushings from both Cage and Gear Plate using a bushing
removal tool. This procedure will also push out the Output Shaft Bearing that has
more than likely remained assembled to both of these components.
Photo TR-63, 64 & 65
51. Remove the Bearing from the Input Shaft. Place the Input Shaft into an aluminum
jawed vise, lightly clamping it to the High Gear. The vise, need only make contact
with the gear. Being the Bearing is slightly larger in diameter than the High Gear,
the vise jaws will hold the bearing up while gently tapping the Input Shaft down
with a soft faced mallet. Photo TR-66
TR-62
TR-64 TR-65
TR-66
TR-63
