Ontario Drive & Gear Limited www.odg.com
PH.(519)- 662-2840 FAX (519)- 662-2421
Argo Service Manual Transmission
TR-31
TR-90
12. Set the assembled Aluminum Cage into an assembly stand or an aluminum jawed
vise Photo TR-91
14. LOCTITE the (3) threaded holes of the Aluminum Cage with Red 271 LOCTITE.
Photo TR-94
15. Assemble the Gear Plate to the Aluminum Cage. Align the top of the Pinions in the
Cage, with the Oilite Bushings in the Gear Plate. Photo TR-95 & 96
13. Install (6) Pinions into the Oilite Bushings of the Aluminum Cage alternating the
Pinions in an up and down manner as shown in Photo TR-92 & 93
TR-91
TR-92 TR-93
TR-94 TR-95
