System Control
ARM DDI 0500D Copyright © 2013-2014 ARM. All rights reserved. 4-41
ID021414 Non-Confidential
Table 4-49 shows the ID_AA64ISAR0_EL1 bit assignments.
To access the ID_AA64ISAR0_EL1:
MRS <Xt>, ID_AA64ISAR0_EL1 ; Read ID_AA64ISAR0_EL1 into Xt
Register access is encoded as follows:
4.3.21 AArch64 Memory Model Feature Register 0, EL1
The ID_AA64MMFR0_EL1 characteristics are:
Purpose Provides information about the implemented memory model and memory
management support in the AArch64 Execution state.
Usage constraints This register is accessible as follows:
Table 4-49 ID_AA64ISAR0_EL1 bit assignments
Bits Name Function
[63:20] - Reserved,
RES0.
[19:16] CRC32
0x1 CRC32 instructions are implemented.
[15:12] SHA2 Indicates whether
SHA2 instructions are implemented. The possible values are:
0b0000 No SHA2 instructions implemented. This is the value if the implementation does not include the
Cryptography Extension, or if it is disabled.
0b0001 SHA256H , SHA256H2 , SHA256U0 , and SHA256U1 implemented. This is the value if the implementation
includes the Cryptography Extension.
All other values reserved.
[11:8] SHA1 Indicates whether
SHA1 instructions are implemented. The possible values are:
0b0000 No SHA1 instructions implemented. This is the value if the implementation does not include the
Cryptography Extension.
0b0001 SHA1C , SHA1P , SHA1M , SHA1SU0 , and SHA1SU1 implemented. This is the value if the implementation
includes the Cryptography Extension.
All other values reserved.
[7:4] AES Indicates whether AES instructions are implemented. The possible values are:
0b0000 No AES instructions implemented. This is the value if the implementation does not include the
Cryptography Extension.
0b0010 AESE , AESD , AESMC , and AESIMC implemented, plus PMULL and PMULL2 instructions operating on 64-bit
data. This is the value if the implementation includes the Cryptography Extension.
All other values reserved.
[3:0] - Reserved,
RES0.
Table 4-50 ID_AA64ISAR0_EL1 access encoding
op0 op1 CRn CRm op2
11 000 0000 0110 000
EL0
EL1
(NS)
EL1
(S)
EL2
EL3
(SCR.NS = 1)
EL3
(SCR.NS = 0)
-RORORORO RO
