System Control
ARM DDI 0500D Copyright © 2013-2014 ARM. All rights reserved. 4-124
ID021414 Non-Confidential
Figure 4-70 ISR_EL1 bit assignments
Table 4-114 shows the ISR_EL1 bit assignments.
To access the ISR_EL1:
MRS <Xt>, ISR_EL1 ; Read ISR_EL1 into Xt
Register access is encoded as follows:
4.3.78 CPU Auxiliary Control Register, EL1
The CPUACTLR_EL1 characteristics are:
Purpose Provides
IMPLEMENTATION DEFINED configuration and control options for
the processor. There is one 64-bit CPU Auxiliary Control Register for each
core in the cluster.
Usage constraints This register is accessible as follows:
31 98765
0
ReservedFIA
Reserved
Table 4-114 ISR_EL1 bit assignments
Bits Name Function
[31:9] - Reserved,
RES0.
[8] A External abort pending bit:
0 No pending external abort.
1 An external abort is pending.
[7] I IRQ pending bit. Indicates whether an IRQ interrupt is pending:
0 No pending IRQ.
1 An IRQ interrupt is pending.
[6] F FIQ pending bit. Indicates whether an FIQ interrupt is pending:
0 No pending FIQ.
1 An FIQ interrupt is pending.
[5:0] - Reserved,
RES0.
Table 4-115 ISR_EL1 access encoding
op0 op1 CRn CRm op2
11 000 1100 0001 000
EL0
EL1
(NS)
EL1
(S)
EL2
EL3
(SCR.NS = 1)
EL3
(SCR.NS = 0)
-RWRWRWRW RW
