System Control
ARM DDI 0500D Copyright © 2013-2014 ARM. All rights reserved. 4-138
ID021414 Non-Confidential
4.4.2 c1 registers
Table 4-123 shows the 32-bit wide system registers you can access when the processor is in
AArch32 state and the value of CRn is c1.
d. The value is 0x09200003 if the L2 cache is not implemented.
e. The reset value is the value of the Multiprocessor Affinity Register.
Table 4-123 c1 register summary
CRn Op1 CRm Op2 Name Reset Description
c1 0 c0 0 SCTLR
0x00C50838
a
System Control Register on page 4-191
1ACTLR
0x00000000 Auxiliary Control Register on page 4-196
2CPACR
0x00000000 Architectural Feature Access Control Register on page 4-197
c1 0 SCR
0x00000000 Secure Configuration Register on page 4-199
1SDER
0x00000000 Secure Debug Enable Register on page 4-201
2NSACR
0x00000000
b
Non-Secure Access Control Register on page 4-202
c3 1 SDCR
0x00000000 Secure Debug Control Register on page 4-204
4c00HSCTLR
0x03C50838 Hyp System Control Register on page 4-207
1 HACTLR
0x00000000 Auxiliary Control Register, EL2 on page 4-55
c1 0 HCR
0x00000000 Hyp Configuration Register on page 4-211
1HDCR
0x00000006 Hyp Debug Control Register on page 4-217
2HCPTR
0x000033FF
c
Hyp Architectural Feature Trap Register on page 4-221
3HSTR
0x00000000 Hyp System Trap Register on page 4-236
4 HCR2
0x00000000 Hyp Configuration Register 2 on page 4-216
7HACR
0x00000000 Hyp Architectural Feature Trap Register on page 4-221
a. The reset value depends on inputs, CFGTE, CFGEND, and VINITHI. The value shown in Table 4-122 on page 4-137 assumes
these signals are set to LOW.
b. If EL3 is AArch64 then the NSACR reads as
0x00000C00 .
c. The reset value depends on the FPU and NEON configuration. If Advanced SIMD and Floating-point are implemented, the reset
value is
0x000033FF . If Advanced SIMD and Floating-point are not implemented, the reset value is 0x0000BFFF .
