System Control
ARM DDI 0500D Copyright © 2013-2014 ARM. All rights reserved. 4-153
ID021414 Non-Confidential
4.4.25 AArch32 Virtualization registers
Table 4-145 shows the Virtualization registers. See the ARM
®
Architecture Reference Manual
ARMv8, for ARMv8-A architecture profile for more information.
Table 4-145 Virtualization registers
Name CRn Op1 CRm Op2 Reset Width Description
VPIDR c0 4 c0 0
0x410FD032
32-bit Virtualization Processor ID Register on page 4-189
VMPIDR 5
-
a
32-bit Virtualization Multiprocessor ID Register on page 4-190
HSCTLR c1 4 c0 0
0x30C50838
32-bit Hyp System Control Register on page 4-207
HACTLR 1 UNK Hyp Auxiliary Control Register on page 4-205
HCR c1 0
0x00000000
32-bit Hyp Configuration Register
HDCR 1
0x00000006
32-bit Hyp Debug Control Register on page 4-217
HCPTR 2
0x000033FF
b
32-bit Hyp Architectural Feature Trap Register on page 4-221
HSTR 3
0x00000000
32-bit Hypervisor System Trap Register
HTCR c2 4 c0 2 UNK 32-bit Hyp Translation Control Register on page 4-232
VTCR c1 2 UNK 32-bit Virtualization Translation Control Register
HTTBR - 4 c2 - UNK 64-bit Hyp Translation Table Base Register
VTTBR - 6 c2 - UNK 64-bit Virtualization Translation Table Base Register
HADFSR c5 4 c1 0
0x00000000
32-bit Hyp Auxiliary Data Fault Status Syndrome Register on
page 4-246
HAIFSR 1
0x00000000
32-bit Hyp Auxiliary Instruction Fault Status Syndrome Register
on page 4-246
HSR c2 0 UNK 32-bit Hyp Syndrome Register on page 4-246
HDFAR c6 4 c0 0 UNK 32-bit Hyp Data Fault Address Register
HIFAR 2 UNK 32-bit Hyp Instruction Fault Address Register
HPFAR 4 UNK 32-bit Hyp IPA Fault Address Register
HMAIR0 c10 4 c2 0 UNK 32-bit Hyp Memory Attribute Indirection Register 0
HMAIR1 1 UNK 32-bit Hyp Memory Attribute Indirection Register 1
HAMAIR0 c3 0
0x00000000
32-bit Hyp Auxiliary Memory Attribute Indirection Register 0 on
page 4-263
HAMAIR1 1
0x00000000
32-bit Hyp Auxiliary Memory Attribute Indirection Register 1 on
page 4-263
HVBAR c12 4 c0 0 UNK 32-bit Hyp Vector Base Address Register
a. The reset value is the value of the Multiprocessor Affinity Register.
b. The reset value depends on the FPU and NEON configuration. If Advanced SIMD and Floating-point are implemented, the reset value is
0x000033FF
. If Advanced SIMD and Floating-point are not implemented, the reset value is
0x0000BFFF
.
