System Control
ARM DDI 0500D Copyright © 2013-2014 ARM. All rights reserved. 4-28
ID021414 Non-Confidential
4.3.12 AArch32 Instruction Set Attribute Register 0
The ID_ISAR0_EL1 characteristics are:
Purpose Provides information about the instruction sets implemented by the
processor in AArch32.
Usage constraints This register is accessible as follows:
Configurations ID_ISAR0_EL1 is architecturally mapped to AArch32 register
ID_ISAR0. See Instruction Set Attribute Register 0 on page 4-172.
Attributes ID_ISAR0_EL1 is a 32-bit register.
Figure 4-11 shows the ID_ISAR0_EL1 bit assignments.
Figure 4-11 ID_ISAR0_EL1 bit assignments
Table 4-33 shows the ID_ISAR0_EL1 bit assignments.
To access the ID_ISAR0_EL1:
EL0
EL1
(NS)
EL1
(S)
EL2
EL3
(SCR.NS = 1)
EL3
(SCR.NS = 0)
-RORORORO RO
31 28 27 24 23 20 19 16 15 12 11 8 7 4 3 0
RES0 Divide Debug Coproc CmpBranch Bitfield BitCount Swap
Table 4-33 ID_ISAR0_EL1 bit assignments
Bits Name Function
[31:28] - Reserved,
RES0.
[27:24] Divide Indicates the implemented Divide instructions:
0x2 • SDIV and UDIV in the T32 instruction set.
• SDIV and UDIV in the A32 instruction set.
[23:20] Debug Indicates the implemented Debug instructions:
0x1 BKPT .
[19:16] Coproc Indicates the implemented Coprocessor instructions:
0x0 None implemented, except for separately attributed by the architecture including CP15,
CP14, Advanced SIMD and Floating-point.
[15:12] CmpBranch Indicates the implemented combined Compare and Branch instructions in the T32 instruction set:
0x1 CBNZ and CBZ .
[11:8] Bitfield Indicates the implemented bit field instructions:
0x1 BFC , BFI , SBFX , and UBFX .
[7:4] BitCount Indicates the implemented Bit Counting instructions:
0x1 CLZ .
[3:0] Swap Indicates the implemented Swap instructions in the A32 instruction set:
0x0 None implemented.
