Aspen Avionics Evolution EFD 1000 C3 Pro PFD - Figure 4-46 360;ARC Hot Key; Select Compass Type

CHAPTER 4 REFERENCE GUIDE
Page 4-30
091-00019-001 REV B
EFD1000 C3 Pro PFD Pilot’s Guide
Select Compass Type
1. Press the 360/ARC Hot Key (Figure 4-46) to alternately select either the 360°
or ARC Compass Mode.
The Navigation Display changes and the Hot Key label reects the currently selected
Compass Mode (Figures 4-47 and 4-48).
Figure 4-47
ARC CDI Compass Mode
Figure 4-48
360˚ Compass Mode
Figure 4-46
360/ARC Hot Key
