Aspen Avionics Evolution EFD 1000 C3 Pro PFD - Conventions; Terminology

EFD1000 C3 Pro PFD Pilot’s Guide
Page xxvii
091-00019-001 REV B
Conventions
The following conventions, functionality, terminology, color philosophy,
and denitions are used in this manual and on the EFD1000 PFD.
Covered Functionality
This guide covers all the functionality available in the EFD1000 PFD and the optional
Hazard Awareness Trac Overlay functionality.
See Aspen Avionics’ document number 091-00006-001 EFD1000/500 MFD Pilot’s Guide
for complete instructions on the EFD1000 MFD and the EFD500 MFD.
Terminology
The term “PFD”, is used throughout this Pilot’s Guide and refers to the EFD1000 PFD.
Figure 1 shows a typical EFD1000 PFD display. This guide uses the terminology listed in
Table 1 when referring to specic parts of the PFD and Chapter 4 provides an in-depth
discussion and step-by-step instructions for all the available functionality.
