EFD1000 C3 Pro PFD Pilot’s Guide
Page xxviii
091-00019-001 REV B
Term Example
Buttons REV Button, Range Buttons, MENU Button
Hot Keys / Menu Keys Five keys on the lower right of the display
Buttons
Lower Left Button, CDI Navigation Source Select Button,
Lower Right Button
Knobs Left (CRS) Knob, Right (HDG) Knob
Navigation Display
Data Bar
Attitude Display
Table 1
EFD1000 PFD Display, Knobs , Buttons, and Keys
Figure 1
EFD1000 PFD Display, Knobs , Buttons, and Keys
NOTE
As the number of colors used on the display is limited, to ensure adequate color
dierentiation under all lighting conditions, there are a few cases where a given color is
used in a slightly dierent context than described in Table 2.
