CHAPTER 4 REFERENCE GUIDE
Page 4-42
091-00019-001 REV B
EFD1000 C3 Pro PFD Pilot’s Guide
Select the Single-Line Bearing Pointer Source
1. Press the Single-Line Bearing Pointer Button (Lower Left Button, Figure 4-80)
until the desired navigation source is shown above the Button.
Select the Double-Line Bearing Pointer Source
1. Press the Double-Line Bearing Pointer Button (Lower Right Button,
Figure 4-81) until the desired navigation source is shown above the Button.
Figure 4-80
Single-Line Bearing Pointer and Button
Figure 4-81
Double-Line Bearing Pointer and Button
NOTE
A VOR that is tuned to a localizer frequency is
considered an invalid Bearing Pointer source since
Localizer signals provide no bearing information.
