Color Philosophy
Table 2 provides the operational philosophy of color usage on the PFD display.
COLOR PURPOSE COLOR PURPOSE
RED
Used to indicate ight envelope and system limits, and
for warning annunciations that require immediate pilot
recognition and which may require immediate pilot
correction or compensatory action.
GREEN
Used for navigation information or mode data related to
or provided by the navigation source currently selected for
display on the Course Deviation Indicator (CDI) (i.e., navigation
deviations, equipment operating state, waypoint information).
Green is also used to indicate status of user controls (i.e., ON,
enabled, or active).
AMBER
Used to indicate abnormal information sources, and for
caution information that requires immediate pilot awareness
and for which subsequent pilot action may be required.
WHITE
Used to show primary ight data (e.g., IAS, ALT, HDG), scales,
and Menu items that are selectable for editing.
MAGENTA
Used for pilot-selectable references (Bugs) enabled for editing,
for depicting the active GPS navigation leg on a moving map
display, and for depicting the ight director bar.
GRAY
Used to show supplemental ight data and for Hot Key and
Menu legends that are OFF, disabled, or inactive.
CYAN
Used to indicate editable values that are not currently selected
for editing. CYAN is also used to display GPS track marker,
bearing pointers, proximity and other trac icons.
BLUE
Used to indicate the sky.
BROWN
Used to indicate the ground.
Table 2
Color Guide
