3.1. Quick Controls Overview
Chapter 2 explains the PFD controls in detail. The following is a quick summary:
Knobs
(see Chapter 2, Section 2.2.1 for details)
The Left or Right Knob each has a Home State, to which it returns after 10 seconds of
inaction. The Left Knob is the CRS knob, and the Right Knob is the HDG knob.
• The current function of each knob is shown by its State, displayed
immediately above the knob. If the Knob State is shown in magenta, turning
the knob will change the value of the function shown. If the legend is shown
in cyan or green, turning the knob will have no eect.
• From the Home State, rotating the knob one click or pressing the knob once
will “wake up” and enable the current function to be set (Knob State color
changes from cyan to magenta). Successive presses of the knob will cycle
through the functions that the knob can control. When the function you want
to change is shown in magenta, turning the knob will change its value.
• The Left Knob sets the Course Pointer (CRS, except when Auto Course Select
is enabled) and Indicated Airspeed Bug (IAS).
• The Right Knob sets Heading (HDG), Selected Altitude (ALT), Barometric
Pressure Setting (BARO Hot Key selected), and Approach Minimums (MIN Hot
Key selected).
• Pressing and holding a knob syncs the selected function.
