Aspen Avionics Evolution EFD 1000 C3 Pro PFD - Figure 5-23 Editing Va Vspeed; Set Textual Vspeed Labels

CHAPTER 5 CUSTOMIZING THE EFD1000 PFD
Page 5-14
091-00019-001 REV B
Page 5-15
091-00019-001 REV B EFD1000 C3 Pro PFD Pilot’s Guide
Set Textual Vspeed Labels
1. Press the MENU Button.
2. Rotate the Right Knob to the appropriate Vspeed Menu page (Figure 5-22).
3. Press the appropriate Vspeed Menu Key.
The menu label turns magenta, and the EDIT VALUE label displays above the
Right Knob (Figure 5-23).
4. Rotate the Right Knob to the desired value (Figure 5-24).
5. Select another Menu Key and edit another Vspeed or press the MENU Button
to exit.
Figure 5-22
VSPEEDS A
Figure 5-23
Editing Va Vspeed
Figure 5-24
Va Vspeed Set With New Value
NOTE
A typical installation sets the Airspeed Textual Markers to UNLOCKED, allowing the pilot
to edit the indicated Vspeed labels. If the Vspeed setting was LOCKED during installation,
no pilot adjustment is allowed.
