CHAPTER 5 CUSTOMIZING THE EFD1000 PFD
Page PB
091-00019-001 REV B
Page 5-1
091-00019-001 REV B EFD1000 C3 Pro PFD Pilot’s Guide
Chapter 5
Customizing the PFD
5.1. Menu Overview
The following tables and gures provide a brief overview of each menu page and its
menu options.
KEY DESCRIPTION OPTIONS
Displays Airspeed and
Altitude Tapes
1
DISABLE or ENABLE
Radio Altitude DISABLE or ENABLE
Auto Course Select DISABLE or ENABLE
ARC Compass Mode HSI or CDI
AHRS Reset Action
Table 5-1
Menu – GENERAL SETTINGS A
Figure 5-1
GENERAL SETTINGS A
1. Available only in those installations where an additional airspeed indicator and
altimeter are added or retained within the pilot’s maximum field of view
