Aspen Avionics Evolution EFD 1000 C3 Pro PFD - Figure 2-23 EDIT VALUE Displays above Right Knob

CHAPTER 2 CONTROLS AND DISPLAY
Page 2-16
091-00019-001 REV B
Page 2-17
091-00019-001 REV B EFD1000 C3 Pro PFD Pilot’s Guide
Edit Menu Items
1. Press the MENU Button.
2. Navigate to the desired Menu Page.
3. Press the Menu Key of the desired option. The Menu label turns magenta, and
the EDIT VALUE label displays above the Right Knob (Figure 2-23).
4. Rotate the Right Knob to the desired value.
5. Press the Right Knob to return to Menu navigation mode.
6. Press the MENU Button to exit.
NOTE
Pressing the Right Knob returns to Navigation mode
and allows selection of other menu options on dierent
pages. Pressing another menu key on the current menu
page saves any changes made and activates the newly
selected option for editing.
Figure 2-23
EDIT VALUE Displays
Above Right Knob
NOTE
Upon reaching the end of a list of editable menu
options, continued rotation of the knob will not result in
the continuous wrapping through the available editable
menu options. Spinning the knob fully clockwise will
go to the last menu page, while spinning the knob fully
counterclockwise will go to the rst menu page.
