Aspen Avionics Evolution EFD 1000 C3 Pro PFD - Figure 6-29 REV Button off

Page 6-22
091-00019-001 REV B
Page 6-23
091-00019-001 REV B
CHAPTER 6 EXPANDED EMERGENCY AND ABNORMAL PROCEDURES
EFD1000 C3 Pro PFD Pilot’s Guide
ADVISORY
Figure 6-29
REV Button O
Presented when the REV Button is pressed.
Figure 6-30
GPSS On
Presented when GPSS is enabled and the GPS source is valid. Either GPSS1 or GPSS2 may be
annunciated, depending on selection and the number of congured GPS navigators. This also indicates
the autopilot heading source.
NOTE
GPSS will always reflect the GPS Basemap source in the Navigation Display and follow its source.
