CHAPTER 4 REFERENCE GUIDE
Page 4-68
091-00019-001 REV B
EFD1000 C3 Pro PFD Pilot’s Guide
When a trac symbol and the Ownship Symbol partially or completely overlap, the
trac symbol and data block will overlay the ownship symbol.
4.8.1.2. Trac Altitude Filter
There are ve Trac Altitude Filter settings: O, Normal, Unrestricted, Above, and Below
(Table 4-6). Only trac within the selected altitude lter value will display.
Hot Key Label Altitude Filter Level Trac Display Volume
TRFC O None
TFCN Normal ±2,700 ft
TFCU Unrestricted ±9,900 ft
TFCA Above +9,900 ft to -2,700 ft
TFCB Below +2,700 ft to -9,000 ft
Table 4-6
Trac Filter Parameters
The pilot selects the Trac Altitude Filter value by continuously pressing the TRFC Hot
Key, which cycles through each of the lter levels.
Change the Trac Altitude Filter
1. Select the 2/2 Hot Key Menu
2. Press the TRFC Hot Key to select the desired lter level.
The TRFC annunciation displays in the lower left of the display (Figure 4-117).
NOTE
Depending on the position of the Trac Advisory at the
edge of the screen, the trac symbol data block may or
may notdisplay.
NOTE
The altitude lters listed in Table 4-6 are referenced to
your aircraft and the PFD altitudes. The trac sensor
congured with the PFD may have dierent (i.e., lower)
altitude thresholds. Check your trac sensor’s pilot’s
manual for specics.
Figure 4-117
Trac Altitude Filter
