Aspen Avionics Evolution EFD 1000 C3 Pro PFD - Page 209

Page 6-18
091-00019-001 REV B
Page 6-19
091-00019-001 REV B
CHAPTER 6 EXPANDED EMERGENCY AND ABNORMAL PROCEDURES
EFD1000 C3 Pro PFD Pilot’s Guide
WARNINGS
Figure 6-16
Chevrons indicate Pitch Down
Figure 6-17
Chevrons indicate Pitch Up
When the Attitude Indicator display extreme pitch up or extreme pitch down attitudes, the red
chevrons indicate the direction to restore level ight.
Table 6-1
Warning Annunciations
