Installation & Maintenance Manual 11. Installing and Configuring the SBA

Version 6.8 99 Microsoft Lync Server

11.7 Step 7: Cs Database Installation

The Cs Database installation option installs CsDatabase for Lyss and registrar.

Note: This step is not relevant for Microsoft Lync Server 2010 deployments.

 To install the CsDatabase:

1. Select the Setup tab, and then select the 'Cs Database installation' check box; the

following screen appears:

Figure 11-31: Cs Database installation Screen
