User's Manual 540 Document #: LTRT-42060
Mediant 2600 E-SBC
Parameter Description
SNMP Manager
[SNMPManagerIsUsed_x]
Determines the validity of the parameters (IP address and port
number) of the corresponding SNMP Manager used to receive
SNMP traps.
 [0] (Check box cleared) = Disabled (default)

[1]
(Check box selected) = Enabled
Web: IP Address
EMS: Address
CLI: ip-address
[SNMPManagerTableIP_x]
Defines the IP address of the remote host used as an SNMP
Manager. The device sends SNMP traps to this IP address.
Enter the IP address in dotted-decimal notation, e.g.,
108.10.1.255.
Web: Trap Port
EMS: Port
CLI: port
[SNMPManagerTrapPort_x]
Defines the port number of the remote SNMP Manager. The
device sends SNMP traps to this port.
The valid SNMP trap port range is 100 to 4000. The default
port is 162.
Web: Trap Enable
CLI: send-trap
[SNMPManagerTrapSendingEnabl
e_x]
Enables the sending of traps to the corresponding SNMP
manager.
 [0] Disable = Sending is disabled.

[1]
Enable = (Default) Sending is enabled.
Web: Trap User
CLI: trap-user
[SNMPManagerTrapUser_x]
Defines the SNMPv3 USM user or SNMPv2 user to associate
with the trap destination. This determines the trap format,
authentication level, and encryption level. By default, it is
associated with the SNMPv2 user (SNMP trap community
string).
The valid value is a string.
Web: Trap Manager Host Name
CLI: manager-host-name
[SNMPTrapManagerHostName]
Defines an FQDN of the remote host used as an SNMP
manager. The resolved IP address replaces the last entry in
the Trap Manager table (defined by the
SNMPManagerTableIP parameter) and the last trap manager
entry of snmpTargetAddrTable in the snmpTargetMIB. For
example: 'mngr.corp.mycompany.com'.
The valid range is a string of up to 99 characters.
SNMP Community String Parameters
Community String - Read Only
configure system > snmp > ro-
community-string
[SNMPReadOnlyCommunityString
_x]
Defines a read-only SNMP community string. Up to five read-
only community strings can be configured.
The valid value is a string of up to 19 characters that can
include only the following:
 Upper- and lower-case letters (a to z, and A to Z)
 Numbers (0 to 9)
 Hyphen (-)
 Underline (_)
For example, "Public-comm_string1".
The default is "public".
Community String - Read / Write
configure system > snmp > rw-
community-string
[SNMPReadWriteCommunityStrin
g_x]
Defines a read-write SNMP community string. Up to five read-
write community strings can be configured.
The valid value is a string of up to 19 characters that can
include only the following:
 Upper- and lower-case letters (a to z, and A to Z)
 Numbers (0 to 9)
 Hyphen (-)
