Version 5.8 323 October 2009
SIP User's Manual 6. Configuration Parameters Reference
Parameter Description
Web/EMS: TCP Timeout
[SIPTCPTimeout]
Defines the Timer B (INVITE transaction timeout timer) and
Timer F (non-INVITE transaction timeout timer), as defined
in RFC 3261, when the SIP Transport Type is TCP.
The valid range is 0 to 40 sec. The default value is
64*SIPT1Rtx msec.
Web: SIP Destination Port
EMS: Destination Port
[SIPDestinationPort]
SIP destination port for sending initial SIP requests.
The valid range is 1 to 65534. The default port is 5060.
Note: SIP responses are sent to the port specified in the Via
header.
Web: Use user=phone in SIP URL
EMS: Is User Phone
[IsUserPhone]
Determines whether the 'user=phone' string is added to the
SIP URI and SIP To header.
[0] No = 'user=phone' string is not added.
[1] Yes = 'user=phone' string is part of the SIP URI and
SIP To header (default).
Web: Use user=phone in From
Header
EMS: Is User Phone In From
[IsUserPhoneInFrom]
Determines whether the 'user=phone' string is added to the
From and Contact SIP headers.
[0] No = Doesn't add 'user=phone' string (default).
[1] Yes = 'user=phone' string is part of the From and
Contact headers.
Web: Use Tel URI for Asserted
Identity
[UseTelURIForAssertedID]
Determines the format of the URI in the P-Asserted-Identity
and P-Preferred-Identity headers.
[0] Disable = 'sip:' (default).
[1] Enable = 'tel:'.
Web: Tel to IP No Answer Timeout
EMS: IP Alert Timeout
[IPAlertTimeout]
Defines the time (in seconds) that the device waits for a 200
OK response from the called party (IP side) after sending an
INVITE message. If the timer expires, the call is released.
The valid range is 0 to 3600. The default value is 180.
Web: Enable Remote Party ID
EMS: Enable RPI Header
[EnableRPIheader]
Enables Remote-Party-ID (RPI) headers for calling and
called numbers for Tel-to-IP calls.
[0] Disable (default).
[1] Enable = RPI headers are generated in SIP INVITE
messages for both called and calling numbers.
