Installing under Windows
AX3000 Models 80 and 85 - User's Manual 97
Server URL: syntax is [https://]server[:port][/config].
- https: optional use (default: http)
- server: DNS name of IP address of WEB Interface server
- port: optional TCP port (default: 80 for http and 443 for https)
- /config: optional configuration full pathname (default is "/Citrix/PNAgent/config.xml")
Note: being authenticated (username, password and domain) is required before enumerating and
launching published applications. See Chapter 5.2.2.
c) TCP/IP+HTTP Protocol
Resources are accessed via one of the farm server (Name/IP and XML port). A local authentication
may be used to filter out user's resources.
This is a part of the dialog box:
Server and XML Port: DNS name or IP address optionally followed by the XML port (use ':' as
separator)
Example: 192.168.1.154:8080
Note: the Citrix XML port value can be obtained in the Citrix Console or in the Windows registry:
[HKLM]-[System]-[Current Control Set]-[Services]-[Ctxhttp]-[TCPPort].
d) Direct Access
This mode allows a Citrix connection to be established without the use of a published resource.
This is a part of the dialog box:
Server: selected from the server table (see Chapter 3.1.4). A new server can be added by
selecting 'IP address' or 'Server Name'.
5.2.2 - 'Published Resource' Section
A Published Resource can be a Desktop, an Application or a Citrix Server.
