52 AX3000 Models 80 and 85 - User's Manual
3.4 - USB MANAGEMENT
3.4.1 - Specifications
Technical specifications:
- Supported speeds: Low-speed (1.5 Mbits), Full-speed (12 Mbits) and High-speed (480 Mbits)
- Maximal consumption: 500 mA (total current draw for all ports)
Important Note: power hungry non-computing USB devices must not be connected to the thin
client (fans, lights…) as they have the potential to draw too much current and cause damage to the
thin client.
The following USB devices are supported:
- Keyboard,
- Barcode reader,
- Mouse,
- HUB,
- Printer,
- USB-RS232 adaptor,
- Touch screen (classic or multi-touch),
- Mass storage device (memory stick, hard drives, CD/DVD readers…),
- Smartcard reader (or security USB dongle from Aladdin),
- Audio device.
Other USB devices are detected but not supported.
USB devices are hot-pluggable and are dynamically detected by the Axel thin client.
Maximum number of connected USB devices:
- Four keyboards and barcode readers,
- Three mice,
- Two HUBs,
- Four printers or USB-RS232 adaptors,
- One touch screen.
- One mass storage device,
- Two smartcard readers.
- One audio device.
3.4.2 - Connecting a USB Keyboard
The USB keyboard is automatically detected by the Axel thin client.
The USB keyboard settings (nationality, LED initialization...) are displayed and can be changed in
the AX3000’s General Parameters. For more information see Chapter 3.2.1.
Note: multiple keyboards (USB and/or PS2) can be connected. The same settings are used for
both and they can be used simultaneously.
3.4.3 - Connecting a USB Barcode Reader
The USB barcode reader is automatically detected by the Axel thin client. A barcode reader is
treated as a keyboard. See previous chapter.
