Installing under Windows
AX3000 Models 80 and 85 - User's Manual 85
5.1 - MICROSOFT TSE/RDS SESSION
Axel thin clients provide an embedded RDP-compatible protocol. The following table shows key
features available for each operating system:
Number of
colors
(bits/pixel)
Redirection
Printer
COM Port
Audio
USB Port
NT4-TSE
8
-
-
-
-
Windows 2000
8
Yes
-
-
-
Windows 2003
8/15/16/24
Yes
Yes
Play
-
Windows 2008R2
8/16/32
Yes
Yes
Play
Record
-
Windows 2012R2
Windows 2016
16/32
Yes
Yes
Play
Record
Yes
To set a Microsoft TSE/RDS session, enter the AX3000 Set-Up, select the [Configuration]-
[Sessions]-[Session X] menu (where X is the session number to be configured), then select the
"Microsoft TSE/RDS" Session Type. The following box is displayed:
Set the following parameters:
- Server: selected from the server table (see Chapter 3.1.4). A new server can be added by
selecting 'IP address' or 'Server Name'.
- Access Mode: a dialog box which lets Load Balancing and RDS gateway parameters be
changed. See Chapter 5.1.1.
- Connection Properties: See Chapter 5.1.2.
- Authentication: set the "Automatic Logon" function and/or the "Auto-Run" function. See
Chapter 5.1.3.
- Display Parameters: see Chapter 5.1.2.
- Additional Parameters: a dialog box, which lets certain RDP parameters be changed. See
Chapter 5.1.3.
- Redirected Resources: see Chapter 5.1.5.
- Performances: a dialog box, which lets certain parameters be changed. See Chapter 5.1.6.
