Using the Thin Client
AX3000 Models 80 and 85 - User's Manual 73
USB drive status. Only displayed if a USB drive is attached.
- : read in progress
- : write in progress
- : media not present of unsupported format
Attaching or detaching USB devices (when the USB Port
redirection is enabled).
Set Portrait/Landscape mode - See Appendix A.7.2
4.3.2 – 'Classical' Taskbar
From the left to the right the aspect of this taskbar is:
- A 'Desktop' icon to come back to the Local Desktop
- The labels of the predefined sessions with a connection indicator (green when connected).
- Notification icons (See Table 3)
- Date and time (See Chapter 3.2.6)
Example:
Table 3 - Axel Notification Icons ('Classical' taskbar)
Coming back the Local Desktop
Turning off - See Chapter 4.6
Getting thin client information (Firmware/Hardware)
The network status (see Chapter 4.3.1)
Disconnecting the current session. See Chapter 4.7.
USB drive status. Only displayed if a USB drive is attached
- : read in progress
- : write in progress
Set Portrait/Landscape mode - See Appendix A.7.2
4.4 - CONNECTING A SESSION
4.4.1 - Creating a Session
Opening a session can be done through:
- The keyboard: press <Alt><Fx> for a predefined session (see Chapter 3.2.3) or
Ctrl><Alt><O> for the application desktop.
- The mouse: click onto the session icon or the session label in the taskbar.
Note: if the session is 'host free', a dialog box is displayed. The following parameters are required:
- Connection Type: read only information.
- Host: select if from a list or enter its DNS name or its IP address
- TCP Port: the default value is protocol dependent
