Appendix
188 AX3000 Models 80 and 85 - User's Manual
- Pressing <F10> allows selecting the 'default' button. Or, if this button is already selected,
perform the associated action.
Select the [OK] button to save modifications and exit the dialog box. Select the [Cancel] button or
press <Esc> to exit the dialog box without saving modifications.
A.1.3 - Enter Data
When a 'free value" parameter field is selected, a value must be entered (it cannot be selected from
a list).
Note: to indicate ‘free value’ mode, the cursor blinks at the beginning of the field.
During this mode the following keys are enabled:
- <Tab>, <>, <Shift><Tab>, <>: valid the value and move to the next/previous field.
- <Esc>: abandon your changes
- <> and <>: move the cursor within the character string
- <Home> and <End>: move the cursor directly to the beginning or the end of the string
- <Del>: delete the character at the cursor position
- <Backspace>: delete the character before the cursor position
- <Insert>: one of two editing modes (Insertion/Overwrite)
To enter characters with an ASCII code lower than 20 hexadecimal, use a backslash ('\') before the
hexadecimal value. For instance, the 'Esc z' sequence can be encoded by '\1Bz'.
Note: when the character string is longer than the length of the field, two indicators are displayed at
the left and at the right of the field.
A.1.4 - Special Notation
The set-up is a sequence of menus and sub-menus. Define an action by the path followed through
the set-up tree (hierarchy), using the following notation:
[item1]-[item2]-[action]
For example, to perform the above action, select item1 in the main menu, then select item2 in the
sub-menu.
A.1.5 - Exiting the set-up
To exit the set-up, select [Configuration]-[Exit].
If changes have been made while in the set-up, a dialog box appears:
- Select [Yes] to save the modifications and exit the set-up. The new AX3000 settings will then
be stored in NVRAM (non-volatile memory).
- Select [No] to abandon your changes and exit the set-up.
